Non Armored Heat Shrinkable Low Voltage Joint HJM

Non Armored Heat Shrinkable Low Voltage Joint HJM 2018-05-23T21:20:08+00:00

Project Description

Such joints are suitable to be installed on PVC-PE cables with different number of cores. They cover a cross-section of 2.5 to 1200 square millimeters and are used for various types of non-armored cables. Their consumption time is unlimited and they are produced according to CENELEC HD 623 standard.

  • Resistant to UV radiation
  • Small dimensions and easy installation
  • 100% Sealing
  • Indoor space
  • Outdoor space
  • Underground
  • Inside cable tray or duct
  • Jacketing tubing
  • Internal tubing
  • Ferrule
  • Installation manual
Withstand Voltage:
U0/UN (UM) 0.6/1 (1.2) kV
Maximum final length (mm) Cable cross-section (mm2) Code Uo
(kV)
Un
(kV)
Um
(kV)
1000 2.5 – 1200 HJM – SY 0.6 1 1.2
For instance: 4×185 low voltage cable joint with aluminum conductor HJM – 4X185 AL
S = number of cores and cable cross-section (mm2)
Y= (A1/Cu/BI) Type of ferrule
